Product Info:

For application on walls, ceilings and floors, the underground needs to be perfectly even. Wall paints, dry constructions boards, etc. need to be filled and sanded evenly. Afterwards you need to apply a layer of primer. The main use is shielding doors, window frames, boxes, cases, devices, machines and many other technical applications.

• Attenuation: 75 dB
• Self-adhesive with electrically conductive glue
• Weight: 110 g/m² (without protective film), 220 g/m² (with protective film)
• Color: Gray / Brown
• Tensile strength: 90 lbf
• Materials: Polyester, copper, nickel, arylics glue
• Surface conductivity: 0.02 ohm (square resistance)

Processing Instructions

It is best to process the netting with two people. One person holds the sheet on the right and left side in position, with some distance to the underground. The other person removes the protective film and presses the netting with a scraper (e.g. our plastic scraper FVR10) strongly onto the underground. As soon as the netting is glued properly, press it once more strongly onto the underground so that the glue can deploy its best adhesion. We recommend practicing this at first for larger surfaces. Due to the electrical conductivity of the glue, you can fix the sheets with an overlapping – if the edging is bothering you, you can level it out. When using wall paint on top of the netting, please take into consideration that the material contains copper, the pH value of the paint must not be higher than 8 – therefore mineral paints are not permitted to be used on top of it.

Dimensions:

• Width: 90 cm
• Length: By the meter / 100 m roll

• Material thickness: 0.095 mm (without protective film), 0.22 mm (with protective film)
